AmpliPHI™ 3.8 Battery
The AmpliPHI™ 3.8 Battery utilizes advanced Lithium Ferro Phosphate (LFP) chemistry that eliminates cobalt which reduces the risk of thermal runaway, fire propagation, operating temperature constraints, and toxic coolants to deliver more efficient, safer and reliable energy storage. Designed and built with versatility in mind, the AmpliPHI 3.8 Battery features a Battery Management System (BMS) with closed loop communications pre-configured for industry leading inverters that reports SOC and other critical real-time data, optimizing the value of storage and functionality within balance-of-system equipment. Combined with our proven overcurrent protection (OCPD) and accessible 100 Amp DC breaker On/Off switch, installation time is reduced and safety is increased during set-up, making it an ideal solution for battery replacement, expansion of existing systems, or as a new installation for residential and commercial systems, on and off-grid, scalable up to 60 batteries.
Click here to view sell sheet.
Features
Battery Management System (BMS)
Closed-loop communication reports critical real-time data and simplifies installation.
Pair with Leading Inverters
Ready to be integrated industry leading inverters for ease of installation.
Lithium Ferro Phosphate (LFP) Chemistry
Peace of mind that the elimination of cobalt reduces the risk of thermal runaway, fire propagation, operating temperature constraints, and toxic coolants.
Scalable for Any Energy Need
Scale up to 60 batteries to allow for larger storage capacity.
Specifications
| AmpliPHI-3.8-48 | |
| DC Voltages - Nominal | 51.2 VDC |
| Amp-Hours | 75 Ah |
| Rated kWh Capacity |
3.8 kWh DC @ 100% DOD 3.04 kWh DC @ 80% DOD |
| MAX Surge Discharge Rate (10 Minutes) | 100 amps DC (5.1 kW DC) |
| MAX Continuous Discharge Rate | 37.5 Amps DC (1.9 kW DC) |
| MAX Continuous Charge Rate | 37.5 Amps DC (1.9 kW DC) |
| DC Voltage Range¹ | 48 VDC to 56 VDC |
| Depth of Discharge | up to 100% |
| Charging Temperature¹ | 32° to 120° F (0° to 49° C) |
| Operating Temperature¹ | -4° to 140° F (-20° to 60° C) |
| Storage Temperature¹ |
6 months: 14° to 77° F (-10° to 25° C) 3 months: -4° to 113° F (-20° to 45° C) |
| Self-Discharge Rate | < 1% per month (when off) |
| Cycle Life | 10,000+ cycles (@ 80% DOD) |
| Memory Effect | None |
| IP Rating | N/A |
| Weight | 86 lbs. (39 kg) |
| Dimensions (W x H x D) |
13.5 x 14 x 8 in. (15.5” H w/terminals) / 0.88 ft3 (34.3 x 35.6 x 20.3 cm / 0.025 m3) |
| Warranty Period | 15 Years |
| Terminals | 3/8 IN (10 mm) |
| Battery Cables | 6 AWG MINIMUM |
| Installation Manual |
1 Max operating ranges. Refer to Installation Manual for recommended conditions.
All specifications listed are typical/nominal and subject to change without notice.
Engineered and Manufactured in California, USA.
Briggs & Stratton has a policy of continuous product improvement and reserves the right to modify its specifications at any time and without prior notice.
