EG4® 18KPV Inverter
The EG4® 18kPV hybrid inverter/charger is a robust solution for solar users seeking flexibility and efficiency. EMP-hardened to withstand natural or manmade disruptions. The 18kPV Inverter supports both grid-tied and off-grid applications, allowing for ultimate energy independence. With 18kW PV input and 12kW output, the inverter offers high energy handling and can parallel up to 10 units for expanded capacity. A 600V DC input and three MPPTs ensure optimal energy conversion and streamlined cable management. The 18kPV provides split-phase 120/240V or 120/208V output and integrates seamlessly with 48V EG4 or other battery brands. Built-in Wi-Fi enables remote monitoring via the EG4 app, making it ideal for homes and businesses focused on solar savings and energy independence. To learn more, download the spec sheet and user manual.
Features
All-In-One Hybrid Inverter
Capable of running entirely off the grid, using grid electricity, or selling power back to the grid.
Dual Functionality
Utilize both grid-tied and off-grid modes, simultaneously.
Complete System Compatibility
Easily integrates with Briggs & Stratton SimpliPHI 6.6 Battery System for a seamless solar energy solution.
Remote Monitoring
Track performance via EG4’s mobile app.
Easy Control
User-friendly, configurable LCD display.
Specifications
| EG4 18KPV | |
| Battery Input Voltage | 48V |
| Rapid Shutdown Capable | YES |
| Maximum Paired Solar (DC Input) | 21000W |
| Integrated MPPT Charge Controllers | 3 |
| Maximum Continuous Power | 12000W |
| CEC Weighted Efficiency | 96.90% |
| Parallel Stacking | 10 |
| Weight | 121.25 lbs (55kg) |
| Dimensions (W x H x D) | 34.3×20.5×11.2 in. (87×52×28.5 cm) |
| Warranty Period | 10 years |
| Battery Compatibility | Briggs & Stratton® SimpliPHI® 6.6 |
1 See operator’s manual or energy.briggsandstratton.com for complete warranty details.
All specifications listed are typical/nominal and subject to change without notice.
EG4 is a registered trademark of EG4 Electronics.
