Sol-Ark® 18K-2P Hybrid Inverter
The Sol-Ark® 18K-2P hybrid inverter is engineered for the most grueling off-grid or home back-up needs, delivering up to 18kW of continuous power directly from battery storage to support large loads, as well as 36kVA of surge power for 10s for demanding loads like HVAC units and motors. The 18K-2P supports more PV than any other residential inverter (over 40kW when utilizing AC coupled functionality). This power-house unit runs American engineered firmware, keeps your data stateside, and comes standard with a 10-year warranty. To learn more, download the spec sheet and installation manual, or visit Sol-Ark's website.
Features
Max PV
Supports over 40kW of Solar with AC Coupling
Mega Power
50% more power than the leading competitors
Surge Power
Surge to meet Locked Rotor Amps
Data Lock
American Engineered Data Transmission
Specifications
| 18K-2P-LV | |
| Safety Features | PV DC Disconnect Switch, Ground Fault Detection, PV Arc Fault Detection, PV Input Lightning Protection, PV String Input Reverse Polarity Protection, AC Output Breaker - 200A, Surge Protection DC Type II / AC Type II |
| Rapid Shutdown Capable | Yes |
| Integrated MPPT Charge Controllers | 3 |
| Maximum Continuous Power | 18kW |
| Surge Power (5s) | 36kVA |
| Parallel Stacking | Up to 12 in parallel |
| Weight | 62.4 kg / 137 lb |
| Dimensions (W x H x D) | 863 x 464 x 282 mm (34 x 18.3 x 11.1 in) |
| Warranty Period | 10 years |
| Battery Compatibility | Lithium / Lead Acid, 48V |
| Automatic Generator Start | 2 wire start |
| Monitoring | MySolArk App |
| Certifications | UL1741 3rd SB, UL 1741 CRD-PCS, IEEE1547-2018 and interoperability using IEEE2030.5, Hawaiian Electric SRD V2.0, UL1699B PVDC AFCI, CSA C22.2 No.107 |
1 See operator’s manual for complete warranty details.
All specifications listed are typical/nominal and subject to change without notice.
